Applications

• Fastening light-duty metalwork: frames, joist hangers, curtain wall fittings

• Suitable for substrate mounting: blinds, gates, handrails, cable trays, lighting, HVAC supports

• Also ideal where single-point load fixing in concrete is required, such as awning or railing installations

🔧 Installation Steps

1. Drill an 8 mm hole at least 90 mm deep.

2. Clean thoroughly (brush + blow-out) to ensure optimal grip.

3. Insert anchor and tighten hex screw using TX30 bit (or 17 mm socket via SW10).

4. The internal expansion sleeve secures into the substrate.

5. Tighten until washer seats firmly—anchor is ready to carry load.

Why Choose SXRL FUS?

• Streamlined installation for non-structural loads

• Multi-variable anchorage depth, reducing inventory complexity

• ETA-certified performance, including cracked concrete applications

• Excellent load distribution thanks to twin-expansion design

• Pre-assembled convenience, with integrated safety screw and washer

Related Variants & Accessories

• SXRL 8 × 80 FUS R: Stainless steel variant for corrosion-prone or outdoor environments

• Sizes in 10 mm & 14 mm diameters, lengths up to 290 mm, including facade-stand options for compressive loading.

• Accessories: SDS drill bits, torque drivers, cover caps ADT, hex flange washers, and more.

System Approvals

• ETA-07/0121, DoP 0329 valid across substrate types

• Approved for cracked and non-cracked concrete, aerated concrete, perforated brick, solid/lightweight blocks, sand-lime brick, gypsum boards

• Usage includes façade and balcony substructures, metal staircases, and timber elements
